| Designation | TMJL 100 |
| Maximum pressure | 100 MPa (14 500 psi) |
| Volume/stroke | 1,0 cm3 (0.06 in.3) |
| Oil container capacity | 800 cm3 (48 in.3) |
| Length of pressure hose | 3 000 mm (118 in.) |
| Connection nipple | G1/4 quick connection |
| Weight | 13 kg (29 lb) |
| Designation | TMJL 100DU |
| TMJL 100 including THGD 100 |
Hydraulic Pump TMJL 100DU
SKU:HYD000022
100 MPa - (14 500 psi)
The TMJL 100 pump is suitable for use with hydraulic nuts (smaller than or equal to HMV 92E) and for mounting and dismounting bearings or components where a maximum pressure of 100 MPa (14 500 psi) is required. The pump is supplied with 3 000 mm (118 in) pressure hose, quick connect coupling and mating nipple, and pressure gauge. The pump is filled with SKF Mounting fluid LHMF 300 and is supplied with an extra litre of fluid.
Special execution TMJL 100DU
TMJL 100 including THGD 100 digital pressure gauge for use with the SKF Drive-up Method.
Manufacturer : SKF
Description
Features & benefits
- Oil container capacity 800 cm³ (48 in.³)
- Fitted with a pressure gauge
- Packed in a sturdy protective case
Applications
- SKF hydraulic nuts smaller than or equal to HMV 92E
- Oil injection applications where the maximum pressure is 100 MPa (14 500 psi)
- Suitable with SKF hydraulic assisted pullers TMHP series
| Designation | Description |
| TMJL 100-1 | Hand pump (sub-assembly) |
| TMJL 100-2 | Repair kit |
| TMJL 100-3 | Pressure gauge adapter |
| 1077587 | Pressure gauge 100 MPa 100 mm diameter |
| TMJG S100 | Pressure gauge protection sleeve 100 mm |
| 729831 A | Quick connection coupling G1/4 |
| 729832 A | Quick connection nipple G1/4 |
| 729834 | Flexible high pressure hose 150 MPa, 3m long |
| LHMF 300/5 | Mounting fluid (5 litre, 300 mm/s at 20 C) |
| LHDF 900/5 | Dismounting fluid (5 litre, 900 mm/s at 20 C) |
| 728245/3 A | Transport box |
