Single row angular contact bearing MJT1.1/8

Bearing number : MJT1.1/8

Size (mm) : 28.575x71.4375x30.1625

Brand : RHP

Bore Diameter (mm) : 28,575

Outer Diameter (mm) : 71,4375

Width (mm) : 30,1625

Bearing dimensions and specification in RHP catalogue:

d - 28,575 mm

D - 71,4375 mm

B - 30,1625 mm

C - 30,1625 mm

Weight - 0,422 Kg

Basic dynamic load rating (C) - 36,8 kN

Basic static load rating (C0) - 22 kN

(Grease) Lubrication Speed - 5 400 r/min

(Oil) Lubrication Speed - 10 900 r/min
