Single row angular contact bearing MJT1.3/4

Bearing number : MJT1.3/4

Size (mm) : 44.45x107.95x17.4625

Brand : RHP

Bore Diameter (mm) : 44,45

Outer Diameter (mm) : 107,95

Width (mm) : 17,4625

Bearing dimensions and specification in RHP catalogue:

d - 44,45 mm

D - 107,95 mm

B - 17,4625 mm

C - 17,4625 mm

Weight - 1,29 Kg

Basic dynamic load rating (C) - 71 kN

Basic static load rating (C0) - 46,1 kN

(Grease) Lubrication Speed - 3 600 r/min

(Oil) Lubrication Speed - 7 200 r/min
