Manufacturer : Timken
Description
Product Attributes
 |
|
| Bore Diameter (mm) | 52.387 |
| Bore Diameter (inch) | 2.0625 |
| Inner Ring Width B (inch) | 1 |
| Inner ring width B (mm) | 25.4 |
| Max Shaft Fillet Radius R (mm) | 3.5 |
| Max Shaft Fillet Radius R (inch) | 0.14 |
| Dynamic Load Rating C1 (lbs) | 22200 |
| Dynamic Load Rating C1 (N) | 98900 |
| Static Load Rating Co (lbs) | 29200 |
| Static Load Rating Co (N) | 130000 |
| Factor K | 1.55 |
| Factor e | 0.38 |
| Factor Y | 1.59 |
| Precision Level | Class 2 (Standard) Tolerance |
| Unit system | Imperial |
| Weight | 0.449 kg |
