Manufacturer : SKF
Description
Technical specification
DIMENSIONS
| d |
17 mm
|
|
|---|---|---|
| D |
40 mm
|
|
| B |
16 mm
|
|
| d1 |
≈ 24.3 mm
|
|
| D1 |
≈ 32.7 mm
|
|
| r1,2 |
min. 0.6 mm
|
ABUTMENT DIMENSIONS
| da |
min. 21.2 mm
|
|
|---|---|---|
| Da |
max. 35.8 mm
|
|
| ra |
max. 0.6 mm
|
CALCULATION DATA
| Basic dynamic load rating | C |
14.8 kN
|
|---|---|---|
| Basic static load rating | C0 |
9.5 kN
|
| Fatigue load limit | Pu |
0.405 kN
|
| Reference speed |
28 000 r/min
|
|
| Limiting speed |
15 000 r/min
|
|
| Calculation factor | kr |
0.05
|
| Calculation factor | f0 |
13.1
|
MASS
| Mass bearing |
0.09 kg
|
|---|
