Manufacturer : SKF
Description
Technical specification
DIMENSIONS
| d |
60 mm
|
|
|---|---|---|
| D |
130 mm
|
|
| B |
46 mm
|
|
| d1 |
≈ 83.1 mm
|
|
| D1 |
≈ 107 mm
|
|
| r1,2 |
min. 2.1 mm
|
ABUTMENT DIMENSIONS
| da |
min. 72 mm
|
|
|---|---|---|
| Da |
max. 118 mm
|
|
| ra |
max. 2 mm
|
CALCULATION DATA
| Basic dynamic load rating | C |
112 kN
|
|---|---|---|
| Basic static load rating | C0 |
98 kN
|
| Fatigue load limit | Pu |
4.15 kN
|
| Reference speed |
8 500 r/min
|
|
| Limiting speed |
4 500 r/min
|
|
| Calculation factor | kr |
0.06
|
| Calculation factor | f0 |
14
|
MASS
| Mass bearing |
2.65 kg
|
|---|
