Manufacturer : SKF
Description
Technical specification
DIMENSIONS
| d |
85 mm
|
|
|---|---|---|
| D |
150 mm
|
|
| B |
28 mm
|
|
| d1 |
≈ 106.05 mm
|
|
| D2 |
≈ 134.3 mm
|
|
| r1,2 |
min. 2 mm
|
ABUTMENT DIMENSIONS
| da |
min. 96 mm
|
|
|---|---|---|
| da |
max. 105.9 mm
|
|
| Da |
max. 139 mm
|
|
| ra |
max. 2 mm
|
CALCULATION DATA
| Basic dynamic load rating | C |
87.1 kN
|
|---|---|---|
| Basic static load rating | C0 |
64 kN
|
| Fatigue load limit | Pu |
2.5 kN
|
| Limiting speed |
2 800 r/min
|
|
| Calculation factor | kr |
0.025
|
| Calculation factor | f0 |
14.7
|
MASS
| Mass bearing |
1.89 kg
