Manufacturer : SKF
Description
Technical specification
DIMENSIONS
| d |
120 mm
|
|
|---|---|---|
| D |
215 mm
|
|
| B |
40 mm
|
|
| d2 |
≈ 118.1 mm
|
|
| D2 |
≈ 189.2 mm
|
|
| r1,2 |
min. 2.1 mm
|
ABUTMENT DIMENSIONS
| da |
min. 132 mm
|
|
|---|---|---|
| da |
max. 150 mm
|
|
| Da |
max. 203 mm
|
|
| ra |
max. 2 mm
|
CALCULATION DATA
| Basic dynamic load rating | C |
146 kN
|
|---|---|---|
| Basic static load rating | C0 |
118 kN
|
| Fatigue load limit | Pu |
3.9 kN
|
| Limiting speed |
1 900 r/min
|
|
| Calculation factor | kr |
0.025
|
| Calculation factor | f0 |
14.4
|
MASS
| Mass bearing |
5.36 kg
|
|---|
