Manufacturer : SKF
Description
Technical specification
DIMENSIONS
| d |
5 mm
|
|
|---|---|---|
| D |
16 mm
|
|
| B |
5 mm
|
|
| d2 |
≈ 7.5 mm
|
|
| D2 |
≈ 13.4 mm
|
|
| r1,2 |
min. 0.3 mm
|
ABUTMENT DIMENSIONS
| da |
min. 7 mm
|
|
|---|---|---|
| da |
max. 7.4 mm
|
|
| Da |
max. 14 mm
|
|
| ra |
max. 0.3 mm
|
CALCULATION DATA
| Basic dynamic load rating | C |
1.43 kN
|
|---|---|---|
| Basic static load rating | C0 |
0.63 kN
|
| Fatigue load limit | Pu |
0.027 kN
|
| Limiting speed |
28 000 r/min
|
|
| Calculation factor | kr |
0.03
|
| Calculation factor | f0 |
11.8
|
MASS
| Mass bearing |
0.005 kg
|
|---|
