2 Holes Oval Flanged FYTB20TF Housing Only
SKU:2HO000003
2 Holes Oval Flanged FYTB20TF Housing Only
Manufacturer : SKF
Description
Technical specification
| Material |
Cast iron
|
|---|
DIMENSIONS
| Da |
47 mm
|
|
|---|---|---|
| Db1 |
58 mm
|
|
| Db2 |
60.5 mm
|
|
| Dc |
50.8 mm
|
|
| A |
29.5 mm
|
|
| A1 |
11 mm
|
|
| A2 |
19 mm
|
|
| A3 |
3.2 mm
|
|
| A5 |
20.5 mm
|
|
| H |
112 mm
|
|
| J |
90 mm
|
|
| L |
60.5 mm
|
|
| N |
11.5 mm
|
| RG |
1/4-28 UNF
|
|
|---|---|---|
| R1 |
20 mm
|
|
| Rα |
45 °
|
| DN |
6.5 mm
|
|
|---|---|---|
| SWN |
7 mm
|
|
| GN |
1/4-28 SAE-LT
|
| J6 |
74 mm
|
|
|---|---|---|
| J7 |
11.5 mm
|
|
| N4 |
2 mm
|
MASS
| Mass housing |
0.29 kg
|
|---|
MOUNTING INFORMATION
| Recommended diameter for attachment bolts, mm | G |
10 mm
|
|---|---|---|
| Recommended diameter for attachment bolts, inch | G |
0.375 in
|
